aluminum honeycomb panel

Aluminum Honeycomb Panel Introduction
Aluminum honeycomb panel is a kind of sandwich panel consisting of two aluminum plates as face panels and hexagonal aluminum honeycomb cell as core materials,
bonded together by aviation-purpose glue or macromolecule lamination film. Thanks to its superb characteristic of light weight, good strength, hyper flatness, sound and heat proof,
Aluminum honeycomb panel has transferred from aviation industry’s usage to civil application, and tends to be the most popular light weight panel, widely used in façade cladding industry,
 Interior decoration, ceiling, partition, furniture industry, ship hull building and ship decoration, vehicle building and so on.
1. Specifications of Aluminum Honeycomb Panel
A) Total thickness:6mm---200mm
B) Aluminum skin thickness:0.3mm—2mm
C) Width: 300mm----- 2000mm; Length: 200mm----55000mm
D) Special size is available as required.
E) Surface finish: Available with various kinds of colors, in PVDF or PET coating.
Special finish: Granite or marble look, wood grain, silver/gold brush, mirror faced, chameleon.
Customized colors are available upon request.
2. Characteristics
A)Excellent strength
Due to honeycomb structure of numerous I shapes, it is especially wind and other pressure resistant, much stronger than other equivalents.
B) Superb flatness
As the two face panels of aluminum honeycomb material is supported by many vertical honeycomb cell with precisely the same height, the panel is extremely flat in any part.
C)Light weight
The honeycomb structure help the panel save much of raw material, therefore greatly reducing the weight of the whole panel.
 Fifteen mm thick aluminum honeycomb panel with 1mm aluminum face plate, weighs only 6 KG per square meter.
D) Non-combustible or fire retardant
All the composite materials are aluminum, non-combustible, so the aluminum honeycomb panel has good fire retardant property. In any fire break,
the aluminum honeycomb panel can retard fire spreading and increase the safety index.
E)Environmental and completely recyclable
Topace  Aluminum honeycomb panel doesn't contain any toxic materials, doesn't radiate, which is an important property for home decoration or furniture making to achieve a healthy environment. Even it is out of usage, almost all the materials can be recycled, thus effectively protecting the environment.
F)Sound proof and thermal insulation
The hexagonal honeycomb structure can absorb sound quite well, good at sound damping and sound proof. Due to the air inside the core structure, aluminum honeycomb panel can retard thermal transmission to some degrees.
3. Materials of Renoxbell honeycomb panel
A) USA PPG fluorocarbon paint, Sweden Berger fluorocarbon paint
B) USA DuPont Macromolecule sticking film, Japanese Mitsubishi Macromolecule lamination film
C) 3003, 5005 alloy aluminum, /copper/stainless steel
D) World-class honeycomb cell 4.Color
4. Application of aluminum honeycomb panel
· Façade or curtain wall cladding
· Interior wall decoration, ceiling
· Furniture materials, such as tabletop, kitchen washing top, doors
· Boat hulls and boats decoration
· Railway floors, doors, interiors, fairing panels
· Aircraft doors and hatches, floor panels
· Racing car chassis and body panels
